Modular Cleanroom Panel Systems — Rapid-Build Controlled Environments
Modular cleanroom panels are purpose-designed, prefabricated building elements that combine structural rigidity, thermal performance, hygienic surfaces, and airtight joints into a single off-the-shelf system. Metrolabs designs, supplies, and installs complete modular cleanroom enclosures for pharmaceutical, biotech, food, electronics, and hospital facilities across India — from a single ISO Class 8 room to a full multi-room GMP suite.
The Fastest Route to a GMP-Compliant Controlled Environment
A modular cleanroom is a pre-engineered controlled environment built from standardized, interchangeable panel, door, window, and ceiling modules — assembled on-site without wet trades, without plastering, and without the weeks of drying time required by conventional brick-and-mortar construction.
Fastest Time-to-Production
Conventional cleanroom construction takes 6–18 months. Modular panel cleanrooms are typically operational in 4–12 weeks — dramatically accelerating your facility’s path to production, regulatory submission, or accreditation.
Built to Exact Layout Design
Every panel is precision-fabricated to your approved 2D/3D layout plan — including all cutouts for doors, windows, pass-throughs, HVAC connections, and utility penetrations. No site-adapted workarounds. No dimensional surprises.
Permanently Relocatable
Unlike brick construction, a modular cleanroom can be fully dismantled, transported, and rebuilt in a new location — protecting your capital investment across facility moves, production line changes, and plant expansions.
Validation-Ready from Day One
Metrolabs delivers a complete Installation Qualification (IQ) documentation pack with every modular cleanroom — material certificates, joint sealant data, panel performance data, particle count records, and HVAC balancing reports.
Six Modular Cleanroom Panel Configurations
Metrolabs offers modular cleanroom panel systems in six core configurations — each optimized for a different ISO class range, industry, and performance requirement:
Standard PUF Modular System (ISO 6–8)
The most popular modular cleanroom configuration for ISO Class 6–8 pharmaceutical QC labs, food processing, and general industrial cleanrooms. 75–100mm PUF-core panels with PPGI or GI skins, cam-lock joints, H13/H14 HEPA FFU ceiling, and hermetic doors. Fastest build time and lowest cost per square metre for mid-range cleanliness classes.
SS 304 Hygienic Modular System (ISO 5–7)
Stainless Steel 304 faced modular cleanroom panels with PUF or Rock Wool core. Designed for pharmaceutical production, biotech fermentation, and food processing cleanrooms requiring a fully washable, corrosion-resistant interior — capable of withstanding daily chemical wash-down with disinfectants, caustics, and peracetic acid.
SS 316L Sterile Grade Modular Suite (ISO 3–5)
Grade 316L stainless steel faced panels electro-polished to Ra < 0.5 μm for aseptic manufacturing suites, injectable fill-finish areas, and Grade A/B critical zones. Every joint and penetration sealed with VHP-compatible sealant. Compatible with hydrogen peroxide vapour (VHP) and chlorine dioxide decontamination cycles.
Fire-Rated Rock Wool Modular System
Modular cleanroom panels with Rock Wool (mineral wool) core achieving Class A non-combustible fire rating to BS EN 13501-1. Required for multi-storey pharmaceutical facilities, hospital cleanrooms, and any facility where building regulations or insurance specifications mandate non-combustible wall and ceiling construction. Simultaneously provides acoustic isolation up to 52 dB Rw.
FSSAI / HACCP Food-Grade Modular Cleanroom
Food-grade modular cleanroom panels with antibacterial PPGI or SS 304 skin and PIR or Rock Wool core for food processing, FSSAI testing laboratories, and beverage production facilities. Non-toxic panel finish, thermal shock-resistant seals, and drainage-compatible coved skirting design. HACCP and FSSAI compliant from first day of operation.
Portable / Rapid-Deploy Modular Cleanroom
Lightweight aluminium honeycomb panel-based modular cleanroom system designed for rapid deployment, frequent relocation, and minimal floor loading. Specified for aerospace component assembly, defence facilities, mobile pharmaceutical compounding units, and temporary clinical environments. Complete modular unit can be assembled and operational within 1–2 weeks.
Every Modular Cleanroom Component — Engineered to Work Together
A complete modular cleanroom from Metrolabs is more than panels — it is a fully integrated system of engineered components, each specified for your ISO class and compliance requirement:
Wall & Ceiling Panels
PUF, Rock Wool, GRP, or Honeycomb core with GI, PPGI, SS 304, or SS 316L face skins. 50–150mm thickness. Cam-lock joints and pharmaceutical-grade silicone sealant throughout.
Hermetic Cleanroom Doors
Airtight steel or SS doors with brush seals, gaskets, and automatic closers. Single and double leaf options with vision panels and pass-through hatches. Coded access, interlock systems for airlocks.
Fan Filter Units (FFU) with H14 HEPA
Ceiling-integrated Fan Filter Units supplying HEPA H14 filtered (99.995% @ 0.3μm) laminar downflow air. Speed-controlled fans for clean zone air changes adjustment from 20 to 600+ ACH depending on ISO class.
Vision Panels & Pass-Throughs
Flush-mounted double-glazed vision panels for visual monitoring without zone entry. Static and dynamic pass-through boxes with UV decontamination for material transfer between cleanroom zones.
Integrated LED Lighting
GMP-compliant flush-mounted LED panels (IP65+) providing 500–1000 lux at work surface level. IEC 60598 rated, anti-static polycarbonate diffusers, zero particle-shedding design.
Utility Penetrations & Services
Pre-fabricated service penetration collars for electrical conduits, gas lines, compressed air, vacuum, and data cables — all sealed with cleanroom-grade foam-in-place seals to maintain panel integrity.
Matching the Modular Panel System to Your ISO Class
The ISO class you must achieve determines the panel core, skin material, HEPA filter grade, and air change rate. This quick-reference table maps ISO class to the correct Metrolabs modular panel specification:
| ISO Class | US Fed Equiv. | ACH Required | Recommended Panel |
|---|---|---|---|
| ISO 3–4 | Class 1–10 | 300–600+ | SS 316L Sterile System |
| ISO 5 | Class 100 | 240–360 | SS 304 / SS 316L System |
| ISO 6 | Class 1,000 | 150–240 | SS 304 Hygienic System |
| ISO 7 | Class 10,000 | 60–90 | SS 304 / PUF PPGI |
| ISO 8 | Class 100,000 | 20–60 | Standard PUF GI / PPGI |
Integrated HVAC & Air Management
Fan Filter Units (FFU) with H14 HEPA
Ceiling-integrated FFUs provide HEPA-filtered laminar downflow at the correct air velocity and change rate for your specified ISO class — individually speed-controlled for precise room pressure management.
Differential Pressure Control
Positive pressure cascade (from Grade A→B→C→D→corridor) prevents cross-contamination between cleanroom zones. Pressure differential monitoring with real-time display and alarm function.
Temperature & Humidity Control
Precision HVAC systems maintaining temperature ±0.5°C and relative humidity ±2% RH within the cleanroom enclosure — critical for pharmaceutical stability and electronic manufacturing.
Environmental Monitoring System
Continuous particle count monitors, temperature loggers, and differential pressure sensors integrated into a central building management system (BMS) for real-time environmental data logging and 21 CFR Part 11-compliant records.
Modular Cleanrooms Across Every Regulated Industry
Pharmaceutical Manufacturing
GMP-compliant modular cleanrooms for tablet, capsule, injectable, and API production — WHO and US-FDA grade A/B/C/D zones.
Aseptic & Sterile Suites
ISO 3–5 SS 316L modular suites for injectable fill-finish, lyophilization, and aseptic compounding — VHP and H2O2 decontamination compatible.
Biotech & Cell Culture
Controlled environment rooms for cell therapy, gene therapy, mRNA production, and live biologic manufacturing under GMP and ATMPs guidelines.
Food & Beverage Production
FSSAI and HACCP-compliant food-grade modular cleanrooms for food processing, packaging, and high-care production environments.
Electronics & Semiconductor
ISO 4–7 modular cleanrooms for wafer fabrication, PCB assembly, optical components, and precision electronic manufacturing.
Hospital & Modular Theatres
Rapid-build modular operating theatres, NICU, isolation rooms, sterile processing (CSSD), and compounding pharmacy suites.
NABL & Research Labs
Controlled environment rooms for analytical instruments, calibration suites, microscopy, and precision measurement facilities.
Aerospace & Defence
Lightweight honeycomb modular cleanrooms for aerospace component assembly, defence electronics, and satellite payload integration.
Modular vs. Conventional Cleanroom Construction
For most laboratory and production cleanrooms, modular panel construction dramatically outperforms brick, drywall, or site-plastered construction across every metric that matters:
4–12 Weeks vs. 6–18 Months
Modular panel construction eliminates wet trades, curing time, and site-adapted workarounds — getting your facility from design approval to operational status in a fraction of conventional timelines.
Expand or Reconfigure Without Demolition
Add a room, move a wall, or reconfigure a zone layout without structural demolition — modular panels disassemble, new layouts assemble in days rather than months, with no production shutdown.
IQ Package Delivered at Handover
No chasing contractors for as-built drawings. No waiting for fire test reports. Metrolabs delivers a complete IQ documentation pack at cleanroom handover — ready for your regulatory dossier submission.
Single Contractor — Full Scope
Panels, doors, windows, FFUs, lighting, HVAC interface, utility penetrations, coving, epoxy flooring, and IQ documentation — all under one Metrolabs contract with a single project manager.
Modular vs. Conventional Construction
From Consultation to Commissioning — Turnkey Modular Cleanroom Delivery
Metrolabs manages the complete modular cleanroom project lifecycle — design, procurement, fabrication, installation, commissioning, and IQ documentation:
Site Survey & Specification
ISO class, GMP grade, HVAC strategy, compliance standards, and layout requirements assessed. Cleanroom panel system specified with skin, core, and thickness matched to your exact application.
2D / 3D Layout Design
Detailed 2D dimensional drawings and photorealistic 3D visualizations produced. All panel positions, door openings, FFU grid, return grilles, utility penetrations, and airlock zones marked for approval.
Panel Fabrication
Panels precision-cut to approved layout dimensions with all cutouts pre-fabricated off-site. Skins finished and inspected. Hermetic doors, vision panels, and FFUs sourced and quality-checked before delivery.
Assembly, Sealing & Services
Structural tracks, panels, doors, and ceiling grid installed. All joints and penetrations sealed with pharmaceutical-grade silicone. Epoxy cove skirting formed. FFUs, lighting, and utility services connected and tested.
Commissioning & IQ Handover
Particle count certification (ISO 14644-1), HVAC balancing and air change rate verification, temperature mapping, differential pressure commissioning, and full IQ documentation pack issued at handover.
Modular Cleanrooms Meeting Every Major Regulatory Framework
WHO & EU GMP
WHO GMP and EU Annex 1 require GMP-grade cleanrooms with defined particle counts, pressure differentials, air change rates, and validated hygienic surfaces — all delivered by Metrolabs modular systems with IQ documentation.
WHO GMP · EU Annex 1ISO 14644 Cleanroom Standard
ISO 14644-1 particle classification and ISO 14644-4 construction requirements — particle count testing, airflow validation, surface finish specification, and design documentation all provided as standard deliverables.
ISO 14644‑1/‑4NABL & ISO/IEC 17025
NABL-accredited testing laboratory assessors require documented evidence of controlled environment construction, commissioning, and ongoing environmental monitoring — all delivered by Metrolabs as part of the IQ package.
NABL · ISO 17025FSSAI, FDA & HACCP
FSSAI food facility certification, US-FDA food cGMP, and HACCP compliance all require cleanable, controlled production environments — met by Metrolabs food-grade modular cleanroom systems with full compliance documentation.
FSSAI · FDA · HACCPReady to Build Your Modular Cleanroom?
Contact Metrolabs for a free consultation. Our cleanroom engineering team will assess your ISO class, compliance requirements, and facility constraints — then specify the optimal modular panel system, produce 2D/3D layout drawings, and deliver a complete turnkey cleanroom with IQ documentation.
